ASUS may sue motherboard competitors over OC Socket tech

by Mark Tyson on 18 September 2014, 09:45

Tags: ASUSTeK (TPE:2357)

Quick Link: HEXUS.net/qacjcn

Add to My Vault: x

Earlier in the month we heard about Nvidia's virgin voyage to the courts to sue Samsung and Qualcomm over graphics patents. Now we have learned that ASUS is about to get the lawyers in, to defend its latest motherboard OC Socket technology.

DigiTimes reports that Asustek Computer (ASUS) is concerned about Taiwanese rivals such as ASRock, Micro-Star International (MSI) and Gigabyte Technology infringing upon its patented technologies. ASUS launched a new in-house-developed OC Socket to complement its latest Intel X99 chipset motherboards and found that various rivals have followed rather too closely in its footsteps.

It is said that ASUS has undertaken an investigation into what it considers to be infringements and it has discovered evidence to suggest that "supply chain makers leaked confidential OC Socket designs to competitors".

With the fierce competition for motherboard sales, and vendors creating the most attractive differentiating features as they can, it is understandable that ASUS intends to sue to put a stop to IP poaching by its rivals. Right now nothing official has been come out - just this DigiTimes report. So we will have to wait and see if there is any impact on X99 motherboard availability from ASUS rivals.

ASUS's exclusive OC Socket adds extra pins to the CPU socket to eke out the best performance it can. ASUS explains that "Haswell-E (Intel Core i7-5960X, 5930X and 5280K) processors actually have more pads than the reference LGA2011-3 socket design, so ASUS added extra socket pins to tap this resource. OC Socket is an enhancement based on the reference LGA2011-3 design, so for users not overclocking or tweaking voltages in the BIOS, OC Socket does not activate. However for those that do overclock and tune performance, there’s significant benefits." See the comparison picture below.

Incidentally, the last time ASUS was in HEXUS legal news was back in 2011 when Hasbro sued it, in the LA federal court, for use of the 'Transformer Prime' name without prior consent.



HEXUS Forums :: 18 Comments

Login with Forum Account

Don't have an account? Register today!
The day that you can wire up CPU circuits and pass that off as novel and non-obvious to an electronic engineer is the day you know the patent system is fubar for sure.
Yeah, first thing that came to mind is, if ASUS discovered this as there are clearly matching pads on the CPU side, why could other manufacturers not have discovered it independently?
…more to the point, if these were intended for use, why didn't Intel include them in the reference designs. Also, if they are ‘added’, Intel, being the ones who added them, would have known first. Presumably if patentable, they would have done it (if only to protect what is effectively the standard to be used by anyone using their chips from being blocked by a patent on the interface.

If there's more to the ASUS lawsuit than just the pads/pad layout (with them just being a visible part but not the secret sauce), then maybe they have a case.
According to ASUS they asked Intel about what the other pins did and Intel refused to tell them. They had to reverse engineer the socket to see what the pins did. I think they have every right to patent the socket as it was their hard work that made it happen. They wouldn't have a case if Intel did the release the information for the extra pins but they didn't.
The most interesting thing for me is that if ASUS do sue we will find out if.
a) That these are really additional power, ground pins that Asus has no way to patent as that would be Intel IP.
Or b) That these extra pins are just for testing, debugging or no-connect pins, in other words marketing BS.
